BW-F series(2-50G)
SUNDON OZONE
Ozone output: | |
---|---|
Usage: | |
Availability: | |
Quantity: | |
BW-F series(2-12G)
Mode | BW-F2G | BW-F3G | BW-F5G | BW-F7G | BW-F10G | BW-F12G |
Ozone output | 2g/h | 3g/h | 5g/h | 7g/h | 10g/h | 12g/h |
Input voltage | AC220V/50-60HZ(110V 12V optional )(working frequency 21khz, output voltage 4kv) | |||||
Provide gas source | Dry clean air or oxygen | |||||
Power | 20w | 35w | 55w | 65w | 85w | 110w |
Cooling way | Air cooling(Environment Humidity ≤85%RH Temperature: -10~55℃) | |||||
Ozone concentration | oxygen source 50-90mg/L, air source 5-15mg/L | |||||
Gas inflow(L/min) | oxygen 0.5-1 air 6-8 | oxygen 0.5-1 air 10-15 | oxygen 1-1.5 air 15-20 | oxygen 1-2 air 20-25 | oxygen 1-2.5 air 30-40 | oxygen 1-3 air 35-45 |
Ozone tube size(mm) | 90*56*66 | 136*56*53 | 178*56*53 | 225*56*66 | 225*70*85 | 270*70*85 |
Net weight(kg) | 0.5 | 0.6 | 0.7 | 0.8 | 1.4 | 1.5 |
BW-F series(15-50G)
Mode | BW-F15G | BW-F20G | BW-F30G | BW-F50G |
Ozone output | 15g/h | 20g/h | 30g/h | 50g/h |
Input voltage | AC220-240V/50-60HZ(AC110V)(working frequency 12khz, output voltage 4kv) | |||
Provide gas source | Dry clean air or oxygen | |||
Power(w) | 10-130 adjustable | 10-180 adjustable | 10-280 adjustable | 10-450 adjustable |
Cooling way | air cooling(Environment Humidity ≤85%RH Temperature: -10~55℃) | |||
Ozone concentration | oxygen source 60-120mg/l, air source 5-15mg/l | |||
Gas inflow | oxygen 1-4L/min air 40-50L/min | oxygen 1-5L/min air 50-55L/min | oxygen 1-6L/min air 55-65L/min | oxygen 1-10L/min air 75-80L/min |
Ozone tube size | 320*70*88mm | 310*102*102mm | 410*102*102mm | 610*102*102mm |
Net weight(kg) | 2.3 | 3.7 | 5 | 7.4 |
