BW-FF(T) series(3-10G)
SUNDON OZONE
Ozone output: | |
---|---|
Usage: | |
Availability: | |
Quantity: | |
BW-FF series(3-10G)
Mode | BW-FF3G | BW-FF5G | BW-FF7G | BW-FF10G |
Ozone output | 3g/h | 5g/h | 7g/h | 10g/h |
Input voltage | AC220V/50-60HZ(110V 12V optional )(working frequency 21khz, output voltage 4kv) | |||
Provide gas source | Dry clean air or oxygen | |||
Power | 40w | 60w | 70w | 90w |
Cooling way | Double air cooling(Environment Humidity ≤85%RH Temperature: -10~55℃) | |||
Ozone concentration | oxygen source 60-80mg/L, air source 5-15mg/L | |||
Gas inflow | oxygen 0.5-1L/min air 10-15L/min | oxygen 1-1.5L/min air 15-20L/min | oxygen 1-2L/min air 20-25L/min | oxygen 1-3L/min air 30-40L/min |
Ozone tube size | 175*75*100mm | 205*75*100mm | 212*83*120mm | 260*86*125mm |
Net weight | 0.9kg | 1.2kg | 1.7kg | 2.2kg |
BW-FFT series(3-10G)
Mode | BW-FFT3G | BW-FFT5G | BW-FFT7G | BW-FFT10G |
Ozone output | 3g/h | 5g/h | 7g/h | 10g/h |
Input voltage | AC220-240V/50-60HZ(AC110V)(working frequency 12khz, output voltage 4kv) | |||
Provide gas source | Dry clean air or oxygen | |||
Power | 10-40w adjustable | 10-60w adjustable | 10-70w adjustable | 10-90w adjustable |
Cooling way | air cooling(Environment Humidity ≤85%RH Temperature: -10~55℃) | |||
Ozone concentration | oxygen source 60-90mg/l, air source 5-15mg/l | |||
Gas inflow | oxygen 0.5-1L/min air 10-15L/min | oxygen 1-1.5L/min air 15-20L/min | oxygen 1-2L/min air 20-25L/min | oxygen 1-3L/min air 30-40L/min |
Ozone tube size | 175*75*100mm | 205*75*100mm | 212*83*120mm | 260*86*125mm |
Net weight | 1.5kg | 1.9kg | 2.3kg | 2.8kg |
